Ibanez / EHB1505-SWL (Stained Wine Red Low Gloss) [Limited Edition]

EHB Regular Scale 5-String Model with Exotic Wooden Top

EHB regular scale 5-string model with exotic wooden top
Ergonomically designed EHB body design for perfect balance between standing and seated players
The horns are shaped to balance the body and neck for easy holding when playing standing, and the body curve on the treble string side is designed for a good fit and balance, especially when playing seated.
The surface of the body has been contoured to slope at the elbow point, and all body edges that touch the body have been treated with smooth radii.
The back of the body is boldly cut to become thinner toward the bass strings.
This design is intended to enhance the fit when playing while seated and to allow for the angle of the eye when looking at the fingerboard inlays.
Body curves for playing comfort and chambering for a more sensory feel of the body's sound
The player will be more aware of his or her own "sound" by experiencing the vibration inside the body as it is in the hollow body. This also leads to a slight weight reduction.
Body back with a scooped horn back on the treble string side for better access to the high frets.
Poplar burl top/African mahogany body
Pangapanga/walnut 9pcs neck w/graphite reinforcement rod
Panga panga fingerboard / stainless steel frets / luminescent side position inlays
Nordstrand Big Split custom pickups
Vari-Mid 3-Band EQ w/EQ bypass switch (powered by 006P 9V alkaline batteries)
MR5HS monorail bridge / newly developed headpiece designed for EHB
Schaller S-Locks strap pins / Neutrik locking jacks
Soft case for electric guitar included / Finger lamps included (* )

* Note
Double-sided tape is already attached to the back of the included finger lamps, and they are designed to be glued to the body with double-sided tape.
When removing the finger lamps, the paint on the surface of the body may be damaged.
Please be very careful when removing the finger lamps. The customer is responsible for the adhesion and removal of the finger lamps.
S/N: I241117803
Weight:3.19kg
JAN code:2100000824663
Accessories: soft case, wrench for adjustment

[Product Specifications] Neck type : EHB4
Neck type : EHB4 9pc Pangapanga/Walnut neck w/Graphite reinforcement rods
Body : Poplar Burl Top / Selected light weight African Mahogan body
Fretboard : Bound Panga Panga fretboard w/Off-set Abalone dot inlay
Fret : Medium Stainless Steel
Bridge : MR5HS bridge (18mm string spacing)
Neck pickup : Nordstrand Custom Big Split neck pickup
Bridge pickup : Nordstrand Custom Big Split bridge pickup
Equalizer : Vari-mid 3-band EQ w/EQ bypass switch (passive tone control on treble pot)
Machine Head : Ibanez custom headpieces
Hardware color : Black
String gauge : .045/.065/.085/.105/.130 (D'Addario EXL165 + .130)
Scale : 864mm/34"
a : Width at Nut 45mm
b : Width at Last Fret 74mm
c : Thickness at 1st 19.5mm
d : Thickness at 12th 21.5mm
Radius : 500mmR
